Product Overview | Schneider EALU Series SH140/30270 High Performance Servo Motor
Core Positioning:
Schneider Electric”s EALU series servo motor, model SB105/30/08/05/19/P/01/EAKN, is a high-precision, high-reliability drive solution tailored for industrial automation. By integrating Schneider”s advanced motor control technology with the modular EALU design,
this motor excels in scenarios demanding dynamic response, precise positioning, and long-term stability.
Model Analysis | Decoding the SH140/30270 Configuration
1. Series Designation: SH140
- Represents the medium-to-large power range, with an estimated power output of 0.75kW–3kW.
2. Core Parameter Code: 30270
This code encompasses critical specifications such as speed, torque, and encoder resolution.
For example, it may indicate:
- Rated speed: 3000 rpm
- Rated torque: 2.7 Nm
(Actual values depend on the full parameter set.)
3. Configuration Fields: 0/1/00/00/00/00/00
These digits define additional options, including but not limited to:
- Voltage level
- Protection rating (e.g., IP65)
- Communication protocol (e.g., EtherCAT, CANopen)
- Functional add-ons (e.g., brakes, oil seals).
Technical Features | Precision Control Meets High Efficiency
1. Core Performance Parameters
Power & Torque:
- Rated power: Estimated 1.5kW–2.2kW (refer to selection manual).
- Rated torque: 2.7 Nm (example; actual value based on code “270”).
- Peak torque: Exceeds 3× rated torque for short-term overload demands.
Speed Range:
- Rated speed: 3000 rpm (supports high-speed light-load or low-speed heavy-load modes).
- Speed ratio: 1:5000 (stepless regulation for multi-condition switching).
Encoder Resolution:
- Standard configuration: 20-bit absolute encoder (1,048,576 pulses/rev) for micrometer-level accuracy.
2. Electrical & Mechanical Design
Voltage Compatibility:
- Three-phase AC 200V/400V (global industrial grid compatibility).
Protection Rating:
- IP65 (dustproof and waterproof, ideal for humid/dusty environments).
Structural Optimization:
- Low-inertia design: Reduces acceleration time for packaging machinery, robot joints.
- High-inertia design: Enhances low-speed stability for CNC feed axes.
3. Communication & Extension Functions
Bus Protocols:
- Supports EtherCAT, CANopen, Modbus TCP for seamless PLC/HMI integration.
Additional Options:
- Brake: Built-in or external module for vertical-axis anti-fall.
- Oil seal: Special design to prevent lubricant leakage in food processing equipment.
Application Scenarios | Powering Industry 4.0
1. Automated Production Lines
Typical Uses:
- Conveyor belt drives
- Sorting robotic arms
- Assembly robot joints
Advantages:
- High-speed response (<1ms delay) and precise sync control improve production pace.
- Long-life design (MTBF >50,000 hours) reduces downtime costs.
2. CNC Machining & Precision Tools
Typical Uses:
- Spindle drives
- Feed axis control
- Five-axis machining centers
Advantages:
- SB105/30/08/05/19/P/01/EAKN High rigidity and low vibration ensure surface finish quality (Ra ≤ 0.8 μm).
- Full closed-loop control eliminates mechanical errors (e.g., screw backlash).
3. New Energy & Environmental Equipment
Typical Uses:
- Wind turbine pitch systems
- Sewage treatment agitators
- Solar tracking brackets
Advantages:
- SB105/30/08/05/19/P/01/EAKN Wide temperature range (-20°C to +60°C) for extreme environments.
- Corrosion-resistant coating extends outdoor lifespan.
4. Packaging & Printing Machinery
Typical Uses:
- Roll tension control
- Label application
- Bottle rotation positioning
Advantages:
- SH140/30270/0/1/00/00/00/00/00/00 High-resolution encoder enables stepless speed regulation to prevent material stretching.
- Quick start-stop (≥5 m/s² acceleration) boosts efficiency.
Complementary Specifications | Detailed Parameter Breakdown
Mechanical & Electrical Limits
- Max mechanical speed: 4000 rpm
- Nominal voltage: 115–480 V (three-phase)
- Continuous stall torque: 27.8 Nm (115–480 V three-phase)
- Peak stall torque: 90.2 Nm
Physical Dimensions
- Shaft diameter: 24 mm
- Shaft length: 50 mm
- IP rating:
- Motor: IP65
- Hub: IP65 (without shaft seal) / IP54 (with seal)
Thermal & Environmental
- Cooling type: Natural convection
- Max radial force (Fr): 2420 N (1000 rpm) to 1670 N (3000 rpm)
- Max axial force (Fa): 300 N
Learn More: Click here for Schneider ELAU motor details.
ISH070/60017/0/0/00/0/00/00/00 High precision, high dynamic response,
SM100-40-050-P0-45-R1-B0 High precision, high dynamic response,
SM-100/50/030/P1/45/M1/B1 | Schneider | EALU motor,
SH140/30270/0/0/00/00/00/11/00 | Schneider | EALU motor,
SH070/60010/0/0/00/00/00/10/00 Brand new original | In stock supply,
SM100/40/080/P0/45/S1/B0 Brand new original | In stock supply,
SH070/60010/0/0/00/00/00/00/00 Schneider Electric | Quick Delivery,
SH30551P02F2000 Advanced motor control technology,
SB145/20/22/05/24/P/01/64/COKN Brand new original | In stock supply,
ISH100/30025/0/1/00/0/00/11/00 | Schneider | EALU motor,
