Allen-Bradley 1746-NIO4V High Resolution Analog Module

    The Allen-Bradley 1746-NIO4V is a high-resolution analog combination module designed for use in industrial automation environments. It combines 2 input channels and 2 output channels, making it ideal for a wide range of applications including process control, data acquisition, and more.

Model Type:SLC500

Model Number:1746-NIO4V/A

Manufacturer:Allen Bradley

Module Type:Analog Combination Module

Resolution:High Resolution

Number of Input Channels:2

Number of Output Channels:2

Common Mode Voltage Range (Input):-20 to 20 V

Absolute Input Voltage (Max.):±7.5 VDC or ±7.5 VAC RMS

Input Range (Current):-20 to 20 mA

Absolute Input Current (Max.):-30 to 30 mA

Output Range (Voltage):-10 to 10 V – 1 LSB

Full Scale Output Voltage:10 VDC

Overvoltage Protection (Voltage):7.5 VAC RMS

Output Range (Voltage Control):-10 to 10 VDC – 1 LSB

    The Allen Bradley 1746-NIO4V Analog Combination Module is a high-performance component designed for industrial automation systems.

     This module integrates two input channels and two output channels, making it ideal for applications requiring precise control and monitoring.

     Each channel supports a wide range of voltage and current inputs, ensuring compatibility with a variety of sensors and actuators.

     Its robust design includes overvoltage protection, safeguarding against potential damage from unexpected surges.

     The module’s high resolution and accurate voltage and current readings make it an indispensable tool for engineers and technicians working in manufacturing, process control, and other demanding environments.

     The easy-to-install design ensures quick setup, reducing downtime and improving overall system efficiency.
